Description
Overview
The Foxhole MT is a sealed two-way meant for a desk, not a concert. The goal was an honest near-field response that measures flat without DSP or room correction — just a passive crossover designed against real measurements.
A sealed alignment was chosen for its predictable low-frequency rolloff and forgiving placement near walls. The trade is reduced deep bass, which is fine on a desk where a subwoofer can take over below 60 Hz.
Design goals
- Flat on-axis response ±3 dB from 70 Hz to 16 kHz at 1 m
- Sealed enclosure for a clean, gradual bass rolloff
- Passive crossover only — driven directly by a small amplifier
- Buildable in two weekends with hand tools and a router
Specifications
| Frequency response | 58–20,000 Hz (±3 dB) |
|---|---|
| Sensitivity | 84 dB / 2.83V / 1m |
| Nominal impedance | 8 Ω |
|---|---|
| Enclosure volume | 7.5 L sealed |
Bill of Materials
| Component | Qty | Unit | Unit Price | Total | Notes | Buy |
|---|---|---|---|---|---|---|
| SB Acoustics SB15NRXC30-8 midwoofer | 2 | €39.00 | €78.00 | 5.25" paper cone, smooth breakup | ||
| SB Acoustics SB26STCN tweeter | 2 | €28.00 | €56.00 | 1" textile dome | ||
| MDF 18 mm sheet | 1 | €22.00 | €22.00 | One 1.2 × 0.6 m sheet covers a pair | ||
| Crossover components (caps, coils, resistors) | 1 | €34.00 | €34.00 | Per pair, air-core coils on the tweeter | ||
| Binding posts + internal wire | 2 | €9.00 | €18.00 |
Build Guide
Cut and dry-fit the panels
2 h- Label every panel — internal vs external faces matter once you chamfer the driver cutout.
Glue up the enclosure
1 h + cureRoute the driver recesses
1.5 h- Take the chamfer in two passes — MDF tears out if you rush it.
Build and tune the crossover
3 hFinal assembly and measurement
1 hReviews
